Autoclave, Class N ,Vertical Type, STV-AII Series

  1. Multifunctional Automatic Internal Cycle With Drying
  2. Chamber volume: 35L, 50L, 75L, 100L
  3. Working temperature: 50~134ºC
  4. Working pressure: 0.22 Mpa

Share the product


  • Hand wheel translation and quick opening structure
  • Internal steam cycle
  • High quality stainless steel material
  • With drying function
  • Microcomputer automatic control,arbitrary setting sterilization parameters
  • Safety interlocking device
  • Digital display and Touch buttons
  • Standard test interface
  • Self-expanding seal
  • With automatic protection function:over temperature protection; over pressure self discharge protection ; low water level protection; anti dry burning.
  • With stainless steel bucket or basket
  • Buzzer reminder after sterilization, automatic stop.
  • Automatic discharge of cold air, automatic steam exhaust after sterilization.
  • Optional external printer


Volume 35L 50L 75L 100L
Power 3.5kW 3.5kW 4.5kW 4.5kW
Voltage AC 220V, 50HZ
Rated working pressure 0.22 Mpa
Rated working temperature 134℃
Sterilization temperature 50℃~134℃
Temp accuracy ±1℃
Sterilization time setting range 4~120 min
Drying time setting range 0~240min
Chamber volume Ø350×400 Ø350×525 Ø400×625 Ø450×650
Bucket dimension Ø330×320 Ø330×460 Ø380×560 Ø420×540
Basket dimension(optional) Ø320×350 Ø320×240×2 Ø360×280×2 Ø410×300×2
Outer dimension 698×498×940 698×498×1110 770×570×1185 788×588×1255
Packing size
(L× W× H )mm
790×610×1130 800×600×1230 840×610×1310 870×650×1380
Gross/net weight 125/110KG 130/112KG 145/114KG 156/129KG
