Biological Microscope, MSC-B201

  1. Viewing Head: binocular head inclined at 30°IncIined
  2. Stage: Double Layers Mechanical Stage 140X135mm/ 75X50mm
  3. 3W LED Illumination, Brightness Adjustable

Share the product

Description

Specifications

Specification MSC-B201
Viewing Head Compensation free binocular head inclined at 30°IncIined  Interpupillary (55-75mm)
Eyepiece Wide Field eyepiece WF10X20mm
Nosepiece Quadruple Nosepiece
Objective Achromatic Objective 4X,10X,40X,100X
Stage Double Layers Mechanical Stage 140X135mm/ 75X50mm
Condense Abbe NA1.25 with Iris Diaphragm & Filter
Focusing System Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm
Illumination 3W LED Illumination, Brightness Adjustable
Halogen Lamp 100V-240V/ 6V20W
Plan-concave Mirror
Package Styrofoam
Carton
Wooden Case
Filter Blue Filter
