- Max. Speed: 16500r/min
- Max. RCF: 21500×g
- Max.Capacity: 6×50ml
- Temperature Control Range: -20℃～40℃
High Speed Refrigerated Centrifuge, CFGR-B16B
Description
DESCRIPTION
DESCRIPTION
It is suitable for experiments in biology, medicine, agriculture and other fields, and is the first choice for genetic gene, protein nucleic acid PCR experiments.
Advantages
1. Display: 5-inch high-definition touch screen, easy to operate and intuitive display;
2. Safety Protection: Automatically identify 7 different rotors to eliminate potential safety hazards caused by user misoperation;
3. Control: It has 9 files of acceleration and 10 files of deceleration level, which can effectively prevent secondary suspension and have a good centrifugal effect.
4. Scheme：15 groups of programs can be stored for users to use;
5. Performance: AC variable frequency motor, high speed control precision, imported environmental protection compressor;
6. Safety:There are various protections such as overspeed, door protection, imbalance protection, etc. to ensure the safety of human and machine;
7. Convenience:Free switching of speed and RCF；
8. Particularity：Special air duct to ensure the rotor works under normal temperature;
9. Speciality : Airtight rotor, effectively prevent aerosols.
SPECIFICATIONS
SPECIFICATIONS
| Model | CFGR-B16B |
| Max. Speed | 16500r/min |
| Max. RCF | 21500×g |
| Max.Capacity | 6×50ml |
| Speed Accuracy | ±20r/min |
| Time Setting | 0～99h59min59s |
| Temperature Control Range | -20℃～40℃ |
| Temperature Control Accuracy | ±1℃ |
| Compressor | Imported high-performance compressor unit, fluorine-free refrigerant |
| Electricity | AC 220V 50Hz 15A |
| Dimensions(L*W*H) | 650×350×370mm |
| Net Weight | 50kg |
| Package | Wooden Case |
| Package Size | 740*420*520mm |
| Gross Weight | 64kg |
Suitable Rotors and Centrifual Tubes
| Rotor NO. | Max. Capacity | Max.Speed | Max. RCF | Dimension of Centrifugual Tube |
| No.1 Angle Rotor | 12×2.2/1.5mL | 16500r/min | 18300×g | Φ10×42 |
| No.2 Angle Rotor | 24×2.2/1.5mL | 14000r/min | 18756×g | Φ10×42 |
| No.3 Angle Rotor | 48×0.5ml | 12000r/min | 13900×g | Φ8×32 |
| No.4 Angle Rotor | 30×2.2/1.5mL | 14000r/min | 13900×g | – |
| No.5 Angle Rotor | 12×5ml | 12000r/min | 10100×g | Φ13×53 |
| No.6 Angle Rotor | 6×50mL | 13000r/min | 15300×g | Φ29×105 |
| No.7 Angle Rotor | 6×8×0.2mL PCR strips | 13000r/min | 16240×g | – |
Accessories & Package
Accessories & Package
