Inverted Microscope, MSC-IV100

  1. Trinocular Head Inclined at 30°
  2. Interpupillary Distance 48-75mm
  3. LWD Infinite Plan Objective:100×,200×,400×
  4. Infinite Plan Phase Objective:100×,200×

Share the product


Inverted Microscope


Model MSC-IV100
Optical System Infinite Optical System
Viewing head Trinocular Head Inclined at 30°, Interpupillary Distance 48-75mm
Eyepiece EW10X/22 Extra Wide Field Eyepiece EW10X/22
Nosepiece Quintuple Nosepiece
Objective LWD Infinite Plan Objective:10×,20×,40×
Infinite Plan Phase Objective:10×,20×
Stage Plain Stage 160X250mm;Glass Insert;
Attachable Mechanical Stage, X-Y Coaxial Control,Moving Rang120X78mm;
70X180mm Auxiliary Stage 70X180mm;Terasaki Holder;
Petri Dish Holder Φ35mm/Φ54mm/Φ90mm;
Slide Glass Holder Φ54mm
Condenser ELWD Condenser NA 0.3, LWD 72mm (Without Condenser 150mm)
Focusing Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range up 8mm, down 3mm
Centering telescope Centering Telescope (Φ30MM)
Illumination Halogen Lamp 6V 30W
Phase Annulus 10X-20X、40X Phase Annulus Plate(Fixed)
Filter Blue、Green and Ground Glass, Diameter 45mm
Accessories Inverted Fluorescent Attachment
Video Adapter with C Mount

*Optional configuration
