- Parallel output:4 groups
- Input range: 110-250 V is suitable for different countries and regions.
- Output range:5-600v (1v) 1-600ma (1ma) 5-300w (1w)
Power Supply for Universal Electrophoresis Apparatus, GEP-PH-600C
Description
Features:
Display screen: 7-inch super-large touch screen, convenient touch operation, automatic generation of numeric keypad during setting, display of clock timing temperature operation status and various prompt operations.
Step by step storage: 10 programs can be edited and saved, and each program can be run in 10 steps.
Protection function: overcurrent, overload, overtemperature, no-load short-circuit load sudden change protection function
Micro-current: The micro-current output can be kept when no one shuts down after the scheduled operation.
Automatic setting: when one of the constant voltage, current and power indexes, the other two indexes will automatically rise to the maximum value, without artificial adjustment.
Appearance: The appearance is tall, full of sense of technology.
Use:
Suitable for electrophoresis of common protein and nucleic acid, suitable for one machine with multiple channels.
Specifications
| Parallel output | 4 groups |
| Input range | 110~250 V is suitable for different countries and regions. |
| Output range | 5~600v (1V), 1~600mA (1mA), 5~300w (1W) |
| Resolution | voltage (1V), current (1mA) and power (1W) |
| Output type | Constant voltage, constant current and constant power are continuously adjustable, stable and reliable. |
| Timing range | 1 minute ~99 hours and 59 minutes |
| Testing temperature | -20℃~ +85℃ |
| Overall dimensions (W*D*H) | 300* 300* 130mm |
