Stirrer, LCD Digital, Overhead Type, OHS-P Series

Description

DESCRIPTION

OHS-70P OHS-20P/OHS-40P
•Speed 50~1100rpm with control accuracy of ±10rpm.
•Brushless DC motor for long life, maintenance free.
•Constant speed despite viscosity change of the sample.
•Spillage and overload protection safety circuits.
•Remote PC control and data transmission.
•Self – locking drill chuck, tools free.
•Stirring paddle “topcross” design, easy to replace the container.
•Start/run smoothly, prevent sample splatter or overflow.
•Silicone cover protecting drill chuck from erosive vapor.
•LCD display of set and actual speed, torque and time.

SPECIFICATIONS

Specifications	OHS-20P	OHS-40P	OHS-70P
Max. stirring quantity [H₂O]	20L	40L	70L
Speed range	50~2200rpm	50~2200rpm	50~1100rpm
Speed display accuracy	±3rpm	±3rpm	±10rpm
Time settings range	–	–	0-99h59min
Max. torque	40Nžcm	60Nžcm	300Nžcm
Viscosity max.	10000mPa·s	50000mPa·s	100000mPa·s
Weight	2.8kg	2.8kg	3.2kg
Motor type	Brushless DC motor
Voltage	100~240V, 50/60 Hz
Speed display	LCD
Torque display	LCD
Overload protection display	LCD
Chuck range diameter	0.5~10mm
Motor input/output power	60W/50W	120W/100W	180W/160W
Power	70W	130W	200W
Dimension [WxHxD]	83 x 220 x 186mm
Protection class	IP21
Permissible ambient temperature and humidity	5~40°C,80%RH
Data interface	RS232

Accessories

Plate Stands

Universal Plate Stand (for OHS-20/OHS-20P/OHS-40/OHS-40P/OHS-70P)
Dimension [W×D×H]: 200mm×310mm×780mm Material: stainless steel Cat. No. 18900258

Grand Plate Stand (for OHS-20/OHS-20P/OHS-40/OHS-40P/OHS-70P)
Dimension [W×D×H]: 335mm×463mm×780mm Material: stainless steel Cat. No. 18900497

Stirrer

Stainless Steel Series(for OHS-20/OHS-20P/OHS-40/OHS-40P/OHS-70P)	Propeller stirrer	Cat No. 18900071	Paddle stirrer	Cat No. 18900073
	Shaft length 400mm Stirrer diameter 50mm Material: 304L stainless steel Standard stirring applications at medium and high speed		Shaft length 40cm Stirrer diameter 6.8cm Material: 304L stainless steel For gentle mixing at low and medium speed
	Straight stirrer	Cat No. 18900072	Centrifugal stirrer	Cat No. 18900074
	Shaft length 40cm Stirrer diameter 6cm Material: 304L stainless steel For low viscosity media at medium and high speeds		Shaft length 40cm Stirrer diameter 9cm Material: 304L stainless steel For narrow neck vessels at medium to high speed

PTFE Coating Series(for OHS-20/OHS-20P/OHS-40/OHS-40P/OHS-70P)	Propeller stirrer	Cat No. 18900075	Paddle stirrer	Cat No. 18900077
	Shaft length 400mm Stirrer diameter 50mm Material: PTFE coated Standard stirring applications at medium and high speed		Shaft length 40cm Stirrer diameter 6.8cm Material: PTFE coated For gentle mixing at low and medium speed
	Straight stirrer	Cat No. 18900076	Centrifugal stirrer	Cat No. 18900078
	Shaft length 40cm Stirrer diameter 6cm Material: PTFE coated For low viscosity media at medium and high speeds		Shaft length 40cm Stirrer diameter 9cm Material: PTFE coated For narrow neck vessels at medium to high speed

Grand Series (for OHS-20/OHS-20P/OHS-40/OHS-40P/OHS-70P)	Grand propeller stirrer	Cat No. 18900478	Grand paddle stirrer	Cat No. 18900499
	Shaft length 600mm Stirrer diameter 10cm Material: 316L stainless steel Standard stirrer		Shaft length 60cm Stirrer diameter 10cm Material: 316L stainless steel Gentle mixing for those stratify easily or sensitive to shear
	Grand anchor stirrer	Cat No. 18900498	Grand dissolving stirrer	Cat No. 18900500
	Shaft length 60cm Stirrer diameter 10cm Material: 316L stainless steel Standard stirring or for those easily precipitate		Shaft length 60cm Stirrer diameter 10cm Material: 316L stainless steel Breaking down granules in the mixture with strong shear
