- Main Body: Trinocular head, 45° inclined
- Magnification: Zoom objective 7X-45X
- Eyepiece: WF10X/20mm; *Optional Eyepiece15X/15mm, 20X/10mm, 25X/9mm, 30X/8mm
- Objective:0.7X-4.5X stereo zoom; Zoom Ratio:6.4:1; *Aux Lens：0.5X，2X
- Configurable camera
Trinocular Stereo Microscope, MSC-ST45T
Description
Stereo Microscope
Specifications
| Model | MSC-ST45T |
| Magnification | Zoom objective 7X-45X |
| Eyepiece | WF10X/20mm high-eyepoint, wide-field; Convenient for observers wearing glasses
*Optional Eyepiece15X/15mm，20X/10mm，25X/9mm，30X/8mm |
| Main Body | Trinocular head，45° inclined, 360° rotatable, can be locked in any position desired.Interpupillary Distance adjustment:54-76mm; Diopter adjustment:±5 diopters |
| Objective | 0.7X-4.5X stereo zoom; Zoom Ratio:6.4:1
*Aux Lens: 0.5X, 2X |
| Focusing Mount | Focusing mount with vertical working distance 50mm |
| Stand | Vertical Post：240mm ；Diameter：φ32mm；With φ95mm B/W Plastic & Perspex Plate and Paired Clips；Base Size：200x255x60mm |
| Illumination | Transmitted and reflected 12v/15w halogen； *LED illumination |
| C-Mount | SZM 1X C-Mount；*SZM 0.5X C-Mount；*SZM 0.3X C-Mount |
| Information：3.5X-270X with optional eyepieces and objectives
*Optional configuration |
|
| Package | Carton |
| Package Size L*W*H (mm) | 510*280*380 |
| Net/ Gross Weight (kg) | 6/ 7 |
