- Autocalibration
- Display Accuracy:0.01
- Portableand massive color card database
- Different apertures: Two Apertures / Small Aperture / Big Aperture
- Test Aperture/Illuminated Area:Φ8mm/Φ11mm;Φ4mm/Φ6mm;Φ8mm/Φ11mm，Φ4mm/Φ6mm
Colorimeter, SP-CLR420C, 421C, 422C
Description
Spectral(Big Aperture/Small Aperture)
Spectral(Two Apertures)
Description
It develops new color measurement method of colorimeter with build-in camera to see test area, UV light source for fluorescence color measurement; It can be connected to mobile APP and has unlimited storage memory;With built-in color card, you can find similar colors anytime, anywhere.
Features
- With Auto calibration
- Different apertures: Two Apertures / Small Aperture / Big Aperture
- Supports both SCI and SCE test which is more consistent with result of visual method.
- Many different kinds of test parameters：Opacity, whiteness index, yellowness index and other 30 kinds of test parameters
- Provide 26 kinds of illuminants for choice
- Good repeatability for stable measurement (Delta E*ab 0.06)
- Portableand massive color card database
- Connect to mobile phone APP to create database to upload the color shades from printing, paint, textile color cards.
- No need to carry big and heavy color card, we can find color card database from Colormeter Pro APP and find the closed/similar color easier and faster.
- Cloud database, more convenient to view and upload
- Official color card databases are available.Personal users can update color information to cloud and share between different instruments which make color management much easier.
- Enterpriseusers can create and manage their own color library and formula information in the cloud and share the information to their customers and suppliers through the unique invitation code.
- Better performance than traditional colorimeter
- UV for fluorescence material test
- Camera to see the test area to avoid test error
- Paint color matching software: user can use mobile phone App to achieve color correction function.
Specifications
| Model | SP-CLR420C | SP-CLR421C | SP-CLR422C |
| Type | Spectral（Big Aperture） | Spectral（Small Aperture） | Spectral(Two Apertures) |
| Color | Blue | ||
| Geometry | D/8(diffused illumination,8 degree viewing)
SCI (specular component included),SCE (specular component excluded) |
||
| Repeatability | Chromaticity Value:
Standard deviation ΔE*ab≤ 0.03 Average : dE*ab≤ 0.04 Max.: dE*ab≤ 0.06 (When a white tile is measured 30 times at 5 seconds interval) |
||
| Inter-instrument Agreement | ΔE*ab≤0.4 | ||
| Display Accuracy | 0.01 | ||
| Test Aperture/
Illuminated Area |
Φ8mm/Φ11mm | Φ4mm/Φ6mm | Φ8mm/Φ11mm，
Φ4mm/Φ6mm |
| Color Space and Indices | Reflectance, CIE-Lab, CIE-LCh, Hunter Lab, CIE-Luv, XYZ, Yxy, RGB, Color Difference (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00), Whiteness Index (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), Yellowness Index(ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness Index(My,dM), Staining Fastness, Color Fastness, Tint(ASTM E313-00), Color Density CMYK(A,T,E,M), Metamerism Index Milm, Munsell, Opacity, Color Strength | ||
| Illuminants | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84 | ||
| Color Matching Software | Support color matching on APP( if user buy the color matching software) | ||
| Light Source | LED+UV | ||
| Camera | Yes | ||
| Calibration | Auto | ||
| Software | Android, IOS, Windows | ||
| Accuracy Guarantee | Pass National Metrology Level I | ||
| Observer | 2°，10° | ||
| Sphere Size | 40mm | ||
| Spectroscopic Method | Integrated optics | ||
| Sensor | CMOS Sensor | ||
| Wavelength Interval | 10nm | ||
| Wavelength Range | 400-700nm | ||
| Reflectance Range | 0-200% | ||
| Reflectance Resolution | 0.01% | ||
| Measurement Time | About 1 second | ||
| Interface | USB, bluetooth | ||
| Screen | IPS full color screen ,2.4 inches | ||
| Battery | Rechargeable, 8,000 times continuous tests, 3.7V/3000mAh | ||
| Light Source Lifetime | 10 years, 1 million tests | ||
| Language | English | ||
| Storage | APP Mass Storage | ||
| Dimensions (L*W*H) | 180*60*51mm | ||
| Weight | 280g | ||
Note:
1.Main difference of SP-CLR420C/SP-CLR421C/SP-CLR422C is the aperture size and quantity
2.Illuminated area is same as instrument aperture)
