Homogenizer, Hand-held Type, HMG-160

  1. Speed Range: 8000rpm-32000rpm
  2. Max. Circum. Speed: 6.3-14m/sec
  3. Max. Viscosity: 5,000mPas
  4. Processing range: 0.1-50mL or 1-250Ml
  5. 316L stainless steel shafts are fully autoclavable
  6. All shafts are interchangeable

Share the product

Description

DESCRIPTION

DESCRIPTION

Homogenizer

Description

The sample is cyclically introduced into the narrow space between the stator and rotor moving relatively at high speed, and is rapidly sheared and broken. Tissues like muscle, liver, breast, etc. can be completely homogenized in 10-30 seconds.It can be used in biopharmaceuticals, genetic research, tissue fragmentation, cytoplasmization, pathological analysis, oil-water emulsification, nanomaterial dispersion, dairy homogenization, polymerization, daily cosmetics, ink coatings, fine chemicals, pesticides, prospecting, environmental protection , energy and other fields.

1. Ideal for manual operation due to its lightweight and ergonomic design.
2. Processing range: 0.1-50mL or 1-250ml.
3. 316L stainless steel shafts are fully autoclavable and inert for highly corrosive solutions.
4. All shafts are interchangeable for easy dismantling and cleaning.
5. Speed from 8,000rpm to 32,000 rpm

Homogenizer, Hand-held Type, HMG-160
All shafts are interchangeable.

SPECIFICATIONS

SPECIFICATIONS

Specifications HMG-160
Power Supply 110V-120V/60Hz
220-240V/ 0-60 Hz
Motor Type Universal motor 160 W AC carbon brush motor
Speed Range 8000rpm-32000rpm
Max. Circum. Speed 6.3-14m/sec
Speed Control Dial knob 10 stage
Working Volume (H2O) 0.1-50mL (Dispersing shaft DS-160/5)
1-250mL (Dispersing shaft DS-160/10)
Max. Viscosity 5,000mPas
Material of Dispersing Shaft SS 316L stainless steel, PTFE
Weight 0.54 kg
Dimension (L×W×H) 45mm×55mm×190mm
Noise 72 dB(A)
Operating Environment 0-40℃, 85% rel. humidity
Protection Class IP20

PACKING

PACKING

Homogenizer PACKAGE-2

CERTIFICATE

CERTIFICATE

FDA (5)
