Homogenizer, Hand-held Type, HMG-160

  1. Speed Range: 8000rpm-32000rpm
  2. Max. Circum. Speed: 6.3-14m/sec
  3. Max. Viscosity: 5,000mPas
  4. Processing range: 0.1-50mL or 1-250Ml
  5. 316L stainless steel shafts are fully autoclavable
  6. All shafts are interchangeable

Share the product





1. Ideal for manual operation due to its lightweight and ergonomic design.
2. Processing range: 0.1-50mL or 1-250ml.
3. 316L stainless steel shafts are fully autoclavable and inert for highly corrosive solutions.
4. All shafts are interchangeable for easy dismantling and cleaning.
5. Speed from 8,000rpm to 32,000 rpm

Homogenizer, Hand-held Type, HMG-160
All shafts are interchangeable.



Specifications HMG-160
Power Supply 110V-120V/60Hz
220-240V/ 0-60 Hz
Motor Type Universal motor 160 W AC carbon brush motor
Speed Range 8000rpm-32000rpm
Max. Circum. Speed 6.3-14m/sec
Speed Control Dial knob 10 stage
Working Volume (H2O) 0.1-50mL (Dispersing shaft DS-160/5)
1-250mL (Dispersing shaft DS-160/10)
Max. Viscosity 5,000mPas
Material of Dispersing Shaft SS 316L stainless steel, PTFE
Weight 0.54 kg
Dimension (L×W×H) 45mm×55mm×190mm
Noise 72 dB(A)
Operating Environment 0-40℃, 85% rel. humidity
Protection Class IP20



Homogenizer PACKAGE-2
