Digital ABBE Refractometer, RFT-A3S

  • Range: 1.30000-1.70000 (nD)/0-100%(Brix)
  • Resolution:  0.00001(nD)/0.01%(Brix)
  • Temperature Range (Min. 0.1℃): -2~120℃
  • Display: Color touch screen

Share the product


  1. Measurement of the Brix of sugar solution
  2. Automatic correction of the effect of temperature on the Brix
  3. Prism made of hard glass
  4. Measure the refractive index nD and the mass percentage of sucrose, glucose, F42, F55 HFCS (Brix) of transparent, translucent liquid and solid. The dry solid content of fruit juice, vegetables, soft drinks and canned goods.
  5. Visual targeting, color LCD touch screen display, friendly human-machine interface, intuitive and easy to understand, measurement data can be saved and traced.
    Temperature correction can be made by measuring the hammer.
  6. The original imported LED light source has a wavelength of 589nm with high stability (long-term accuracy of the instrument can be guaranteed), no temperature rise, small size, low power consumption, high brightness, and long life.
  7. The patented optical structure ensures the instrument to improve the measuring accuracy, and the advantages of simple operation and quick targeting are also presented.


Parameters/Model RFT-A3S
Measurement range Refractive index nD: 1.30000-1.72000
Brix: 0~100%
Accuracy Refractive index nD: ±0.0002
Brix: ±0.1%
Measuring resolution Refractive index nD: 0.00001
Brix: 0.01%
Temperature Range (Min. 0.1℃) -20~120℃
Display Color touch screen
Interface RS232/USB
Usage temperature range Room temperature~35℃
Weight (Gross) 12 kg
Overall Dimensions 370mm×240mm×470mm
