Rotary Evaporator, Lab Scale, REV100-P

  1. Evaporating Flask Volume: 50~2000ml
  2. Evaporation capacity(H₂O):1.56L/H
  3. Motor Type:Brushless motor
  4. Lift Mechanism: Automatic
  5. Rotation Speed: 20~280 RPM
  6. Temperature Range: RT ~180℃
  7. LCD Display

Share the product

Description

Features
•Digital display of both rotation speed and heating temperature allows effective control of all distillation processes
•Automatic motor lift releases the evaporating flask to a safe position in case of power failure.
•5L heating bath with wide temperature range from room temp. to 180°C, Water/oil heating mode can be changed only through a switch.
•Overheating protection temperature at 220°C.
•Boil-dry protection, automatically power off if heating without water/oil in the heating bath.
•Speed range from 20 to 280rpm, and interval operation in clockwise and anticlockwise directions for drying process.
•Condenser–cooling surface 1700cm²
•Ejection mechanism ensures easy removal of evaporating flask.
•Patented double spring sealing ring made of PTFE provides an excellent sealing performance.
•Remote function provides PC control and data transmission.
•Optional glassware with explosion proof film available.

SPECIFICATIONS

SPECIFICATIONS

Specifications REV100-P
Evaporating Flask Volume 50-2000ml

(Standard configuration-1000ml)

Receiving Flask Volume 100-2000ml

(Standard configuration-1000ml)

Motor Type Brushless DC motor
Speed Range 20rpm-280rpm
Display LCD (speed, temperature, time)
Clockwise and Anti-clockwise Yes
Heating Temperature Range Room temp. to 180℃
Control Accuracy water: ±1℃ oil: ±3℃
Heating Power 1300W
Stroke Displacement automatic 150mm
Timer Yes
Time Setting Range 1-999min
Interval Time Setting Range 1~999s
Dimension (D×W×H) 465×457×583mm
Weight 15kg
Permissible Ambient Temperature 5℃-40℃
Permissible Relative Humidity 80%RH
Protection Class IP20
USB Interface Yes
Voltage/Frequency 100V-120V/200V-240V 50Hz/60Hz
Power 1400 W
Supporting products REV100-P+ Diaphragm Vacuum Pump VACP-D410+Low Temperature Circulator RECL20-4.5+Vacuum Controller VACC100
